Hydraulic Cone Crusher

Hydraulic Cone CrusherMulti-cylinder with Large CapacityNew Design We manufacture Hydraulic Cone CrusherMulti-cylinder with Large CapacityNew Design. We devote ourselves to mining machinery many years, and our machines have been exported to South Asi

Inquire Whatsapp

Rock Crusher

Product Description

Hydraulic Cone CrusherMulti-cylinder with Large CapacityNew Design

We manufacture Hydraulic Cone CrusherMulti-cylinder with Large CapacityNew Design. We devote ourselves to mining machinery many years, and our machines have been exported to South Asia, South America, Africa, Middle East and some other area. We expect be your partner in China.

1. Product Introduction

Hydraulic cone crusher is the latest crusher equipment designed by our Sankay company. We optimize the design of high speed, large stroke and crushing chamber,it makes the crusher has higher output and higher fine material proportion. Now Hydraulic cone crusher has been widely used in stone production, artificial sand makingand ore dressing production, etc. Itis the most ideal equipment for large stone factories and mining crushing field.

2.Features

1.Large crushing ratio and high working efficiency.

2.Spare parts consumption and operation cost is low.

3.Hydraulic protection and hydraulic clear cavity,high automation and reduce the downtime.

4.Thin oil lubrication system improved Hydraulic cone crusher’s service life.

5.Multi-cylinder crushing cavity, flexible application,strong adaptability.

3.Structure

4. Specification

Model	Cavity	Standard type		Short head type		Power (kw)	Capacity (t/h)
Model	Cavity	Feeding Size (MM)	Discharging Size(MM)	Feeding Size (MM)	Discharging Size(MM)	Power (kw)	Capacity (t/h)
XHP200	Extra Coarse(BC)					132-200	90-250
	Coarse(C)	185	19	76	10
	Medium(m)	125	17	54	6
	Fine(F)	95	13	23	6
	Extra Fine(BF)			10	5
XHP300	Extra Coarse(BC)	230	25			180-250	110-440
	Coarse(C)	210	20	75	10
	Medium(m)	150	15	50	8
	Fine(F)	105	10	20	6
	Extra Fine(BF)			20	6
XHP400	Extra Coarse(BC)	295	30			280-355	140-630
	Coarse(C)	250	25	90	10
	Medium(m)	195	20	50	8
	Fine(F)	110	14	40	6
	Extra Fine(BF)			30	6
XHP500	Extra Coarse(BC)	330	30			355-450	175-790
	Coarse(C)	285	25	90	13
	Medium(m)	200	20	55	10
	Fine(F)	133	16	40	8
	Extra FineBF)			35	6
XHP800	Extra Coarse(BC)	353	32			550-630	260-1200
	Coarse(C)	297	32	155	13
	Medium(m)	267	25	92	10
	Fine(F)	219	16	33	6
	Extra Fine(BF)
